- AWS: A5.14 ERNi-1
- EN ISO : SFA 5.14 Class ERNi-1 (UNS N02061)
- ASME : ASME SFA-5.7/SFA-5.7M
- Alloy: WWNA61
- Conforms to Certification : AWS A5.14 / ASME SFA A5.14
- Weld Process : GMAW, GTAW and ASAW Welding Processes
- Trade Name : Alloy 61, NA61
- Standard Size: Diameter 1.6 mm, 2.0 mm, 2.4 mm & 3.2 mm in cut lengths of 1000 mm each.
- Welding Position : H, F, VU, OH
ERNI 1 Tig Rod, ERNi-1 Filler Wire, ERNI-1 Welding Wire, AWS Class ERNi-1 MIG & TIG Filler Metal Supplier in India
Shanti Metals is the prominent producer and supplier of AWS Class Erni-1 MIG & TIG Welded Wires. We use only pure quality raw materials to produce our Welded Wires using advanced technology and machinery. In addition, we provide these wires in different sizes and lengths in custom form.
Other trade names also know these Welded Wires, including Alloy 61, NICKEL FILLER METAL 61, UTP A 80 NI, and OK AUTROD NI-1..
About AWS Class Erni-1 MIG & TIG Welded Wire:
Alloy 61 Welded Wires is always utilized for the welding of Nickel 200 and 201-grade alloy product. The combination of titanium with carbon preserves a minimum level of free carbon and facilitates the filler metal to be used with Nickel 201.
Properties of AWS Class Erni-1 MIG & TIG Welded Wires:
The NICKEL FILLER METAL 61 Wire has good corrosion resistance,
particularly in alkalis.
Other Features of these are:
- • These Welded Wires are best for welding nickel 200 or 201.
- • It is also used for overlaying steel.
- • It is highly utilized for joining these alloys to stainless steel, carbon steels, or other nickel and copper-nickel base metals.
AWS A5.14 ERNi-1 | Nickel Filler Metal 61 | ERNi-1 MIG & TIG Welding Wire | UNS N02061 MIG and TIG Stick Filler Metal
The UTP A 80 NI Wire is a common purpose engineering material for
applications requiring heat and corrosion resistance. The great features of these wires
are their resistance to high-temperature oxidation. This alloy also has superior
resistance to aqueous media corrosion. In addition, It has high mechanical strength and
is readily formed, machined, and welded.
OK AUTROD NI-1 Welded Wires give resistance to many corrosive solutions and
high-temperature oxidation areas as the aluminum content increase more oxidation
resistance.
Applications of AWS Class Erni-1 MIG & TIG Welded Wires:
- · Trays, baskets, and fixtures are utilized in various heat treatments such as carburizing and carbon nitriding.
- · Refractory anchors, strand annealing and radiant tubes, high-velocity gas burners, etc.
- · Insulating cans in ammonia reformers and catalyst support grids utilized in the nitric acid manufacturing process.
AWS ERNi-1 MIG & TIG Filler Metal Rod & Wire, AWS/ASME 5.14 ERNi-1 MIG & TIG Filler Metal, AWS Class ERNi-1 MIG/TIG Filler Welding Wire, Industrial ERNi-1 MIG / TIG Filler Metal, SFA A5.14 ERNi-1 MIG & TIG Filler Metal, Alloy 61 Welding MIG & TIG Filler Metal
Available Sizes
| .035 x 36 | .045 x 36 | 1/16 x 36 | 3/32 x 36 | 1/8 x 36 |
AWS ERNi-1 Chemical Composition Requirements
| Element | Composition (%) |
| C | 0.15 max |
| Mn | 1.0 max |
| Fe | 1.0 max |
| P | 0.03 max |
| S | 0.015 max |
| Si | 0.75 max |
| Cu | 0.25 max |
| Ni | 93.0 min |
| Al | 1.50 max |
| Ti | 2.0 – 3.5 |
| Other | 0.50 max |
Deposited Chemical Composition % (Typical)
| Element | Composition (%) |
| C | 0.06 |
| Mn | 0.30 |
| Fe | 0.10 |
| Cu | 0.02 |
| P | 0.008 |
| S | 0.003 |
| Si | 0.40 |
| Ni | Balance |
| Ti | 3.0 |
| Al | 0.50 |
Mechanical Properties of Deposited All Weld Metal % (AW)
| Property | Value |
| Tensile Strength | 66,000 psi |
| Yield Strength | 38,000 psi |
| Elongation | 28% |
Deposited Charpy-V-Notch Impact Properties %
Not applicable
Recommended Welding Parameters for TIG,MIG, and SAW Welding of Nickel Alloys
| Process | Diameter of Wire | Voltage (V) | Amperage (A) | Gas |
| TIG | 0.035 inches x 36 | 12-15 | 60-90 | 100% Argon |
| TIG | 0.045 inches x 36 | 13-16 | 80-110 | 100% Argon |
| TIG | 1/16 inches x 36 | 14-18 | 90-130 | 100% Argon |
| TIG | 3/32 inches x 36 | 15-20 | 120-175 | 100% Argon |
| TIG | 1/8 inches x 36 | 15-20 | 150-220 | 100% Argon |
| MIG | .035 inches | 26 – 29 | 150 – 190 | 75% Argon + 25% Helium |
| MIG | .045 inches | 28 – 32 | 180 – 220 | 75% Argon + 25% Helium |
| MIG | 1/16 inches | 29 – 33 | 200 - 250 | 75% Argon + 25% Helium |
| SAW | 3/32 inches | 28 – 30 | 275 – 350 | Suitable Flux may be used |
| SAW | 1/8 inches | 29 – 32 | 350 – 450 | Suitable Flux may be used |
| SAW | 5/32 inches | 30 – 33 | 400 – 550 | Suitable Flux may be used |
Note: Other shielding Gases may be used for Mig and Tig welding. Shielding gases are chosen taking Quality, cost, and Operability into consideration.
Note: Both agglomerated and fused fluxes can be used for submerged arc welding.
Note: The chemical composition of the flux mainly affects the chemistry of the weld metal and consequently its corrosion resistance and mechanical properties.
ERNi-1 Nickel Filler Metal, AWS Class ERNi-1 Metal Inert Gas (MIG) Welding, AWS A5.14 ERNi-1 MIG & TIG Welding Filler Rod, AWS Class ERNi-1 MIG & TIG Filler Metal Stockist in India.
We source from the following Manufacturer Brands & their Trade Names
Oxford Alloys - Alloy 61
Special Metals - NICKEL FILLER METAL 61
UTP - UTP A 80 NI
ESAB - OK AUTROD NI-1
